Elite 2512 UV Flatbed Printer -

Elite 2512 UV Flatbed Printer

Key Features

Single color clean
Double Negative Pressure
Variable Dot Printing
White Ink circulation
Multi layer Printing
ICC profile for all media
Auto ink Refill Alarm
Easy Operational Software
Effect 3D Printing

True Flatbed with Moving Gantry

Advance LED UV lamps – Printer is equipped with advance LED technology of UV lamps, capable of curing quick and all heat sensitive materials. It does not require any warm up or cool down time.
Retractable Media Register Pins – Automated retractable media register pins perfectly position the substrate to facilitate accurate printing.
Print Head Safety Remove – Set of carriage safety sensors on either side of print carriage to protect valuable print head from hitting media in case of irregularities.
Powerful Vaccum – A powerful vacuum holds substrates flat & firmly in place.
3x powered Panasonic Servo Drive – 1 Servo Drive for X and 2 Servo Drive for Y for printer stability and longer life.
Wide Color Gamut. High Durability – HQ+ UV inks dry fast and produce a wide color gamut, enabling the use of a wide variety of materials.

Model	ELITE 2512 – Ricoh Gen6	ELITE 2512 – KM9888H
Printhead	Ricoh Gen6	KM9888H
Print Resolution	635 × 2400 dpi (Max)	400 × 2400 dpi (Max)
Print Head No.	2	2
Print Speed (Express Mode)	15 m²/hr	18 m²/hr
Print Speed (Standard Mode)	12 m²/hr	15 m²/hr
Print Speed (Quality Mode)	10 m²/hr	12 m²/hr

Features	Specifications
Model	Digital Inkjet Printer ELITE 2512
Max. Printing Size	2500mm × 1300mm
Printhead Technology	Drop-on-demand micro piezo-electric digital inkjet printer
Optional Color Configuration	CMYK W, CMYK LcLm, CMYK LcLm W, CMYK CMYK, CMYK W V, CMYK LC LM W V, CMYK LcLm FMFY, CMYK V GV
Optional Color Scale	CMYK + LC + LM + White + Varnish + FM + FY + FG + FO + Primer + Gold Varnish
Max. Media Thickness	0–100mm
Ink Supply System	Negative Pressure Auto Ink Supply
Drying System	UV Lamps – Instant Drying
Media Absorption	Vacuum Enabled
Table Pressure	35 kg/m²
Printable Media	Glass, Ceramic, PVC, Wood, Metal, Sunboard, Sunpack, Acrylic, MDF, Doors and all rigid materials
Interface	USB 2.0
RIP Software	Photoprint / Onyx (Optional)
Power	10 kW / Single Phase / AC 220V, 50/60 Hz
Operational Environment	Temperature: 18°C–22°C; Humidity: 35%–65% RH
Machine Dimensions	4440 × 2145 × 1430 mm

AFTER-SALES SERVICE

✅ Installation & Setup Support
Our trained technicians will assist you with onsite installation and training for smooth operations.

✅ Remote Troubleshooting
Dedicated customer support via phone, video call, and remote desktop sessions for quick resolution.

✅ Spare Parts & Consumables
Ready availability of original spare parts, printheads, and UV inks to ensure uninterrupted operations.

✅ Annual Maintenance Contracts (AMC)
Optional AMCs are available to keep your machine running at peak performance with regular checkups.

FREQUENTLY ASKED QUESTIONS (FAQ)

Q1. What types of materials can be printed on?
A: You can print on various rigid materials like glass, ceramic, wood, MDF, acrylic, metal, PVC, sunboard, and more.

Q2. Does it support white and varnish printing?
A: Yes, the printer supports CMYK+W (White) and CMYK+WV (White + Varnish) configurations.

Q3. What is the maintenance requirement?
A: Regular head cleaning and system checkups are recommended. We provide detailed guidance and support.

Q4. Can I print on dark surfaces?
A: Absolutely! With white ink support, you can easily print on dark or colored surfaces.

Q5. Is training provided?
A: Yes, complete training is provided during installation including software usage and media handling.

Q6. What is the lifespan of the printhead?
A: With proper maintenance,Printheads last for a long time.

Q7. What is the drying time for the prints?
A: The UV lamps provide instant drying, enabling immediate handling or post-processing.
