XLine UV RTR 3200
Delivers exceptional print speed of up to 80 m²/h, making it ideal for high-volume production environments where meeting tight deadlines is crucial.
Handles a wide variety of media, including leather, acrylic, MDF, ceramic tiles, sunboard, wallpapers, and more—providing unmatched versatility for signage, décor, and industrial applications.
Equipped with advanced Ricoh Gen5/Gen6 printheads, offering ultra-fine drop volumes (as low as 5PL) for high-resolution output up to 2400 dpi with crisp details and vibrant color gradients.
Supports extended color configuration including CMYK, White, Light Cyan, Light Magenta, and Varnish—enhancing image depth, smoothness, and surface protection.
Built-in UV-LED curing system ensures instant drying, increased adhesion, and compatibility with heat-sensitive materials, improving productivity and material handling.
Automatic maintenance and head cleaning functions reduce manual intervention, minimize downtime, and maintain consistent print quality.
Rugged and compact design with a machine footprint of 4394 mm × 1675 mm × 1450 mm, making it suitable for modern production floors with limited space.
Compatible with industry-leading RIP software like PhotoPrint and Onyx, enabling precise color management and seamless print workflow integration.
Ideal for diverse applications such as advertising graphics, custom interiors, signage, personalized gifts, and industrial labeling—delivering outstanding results across all projects.
| Parameter | Specification |
|---|---|
| Model | Xline Hybrid |
| Print Technology | Drop-on-demand Micro Piezo-Electric Digital Inkjet Printer |
| Printhead | Ricoh Gen5 / Gen6 |
| Printhead Quantity | Up to 16 |
| Print Resolution | Up to 2400 dpi |
| Print Width | 2100 mm |
| Print Height | Up to 50 mm |
| Drop Volume | Gen5: 7 PL / Gen6: 5 PL |
| Color Configuration | CMYK + White + Light Cyan (Lc) + Light Magenta (Lm) + Varnish |
| Ink Type | UV-LED Ink |
| Drying System | UV LED Lamps |
| Printing Speed | Up to 80 m²/h (under test conditions) |
| Media Compatibility | Leather, Floor Mats, Acrylic, Sunboard, MDF, Advertising Media, Decorative Panels, Handicrafts, Transparent Films, Labels, Gold & Silver Paper, Wallpaper, Wood Panels, Ceramic Tiles, and more |
| RIP Software | PhotoPrint / Onyx |
| Machine Dimensions | 4394 mm (L) × 1675 mm (W) × 1450 mm (H) |
| Machine Weight | 1300 kg |
AFTER-SALES SERVICE
✅ Installation & Setup Support
Our trained technicians will assist you with onsite installation and training for smooth operations.
✅ Remote Troubleshooting
Dedicated customer support via phone, video call, and remote desktop sessions for quick resolution.
✅ Spare Parts & Consumables
Ready availability of original spare parts, printheads, and UV inks to ensure uninterrupted operations.
✅ Annual Maintenance Contracts (AMC)
Optional AMCs are available to keep your machine running at peak performance with regular checkups.
FREQUENTLY ASKED QUESTIONS (FAQ)
Q1. What types of materials can be printed on?
A: You can print on various rigid materials like glass, ceramic, wood, MDF, acrylic, metal, PVC, sunboard, and more.
Q2. Does it support white and varnish printing?
A: Yes, the printer supports CMYK+W (White) and CMYK+WV (White + Varnish) configurations.
Q3. What is the maintenance requirement?
A: Regular head cleaning and system checkups are recommended. We provide detailed guidance and support.
Q4. Can I print on dark surfaces?
A: Absolutely! With white ink support, you can easily print on dark or colored surfaces.
Q5. Is training provided?
A: Yes, complete training is provided during installation including software usage and media handling.
Q6. What is the lifespan of the printhead?
A: With proper maintenance,Printheads last for a long time.
Q7. What is the drying time for the prints?
A: The UV lamps provide instant drying, enabling immediate handling or post-processing.
Wallpaper
High-resolution, customized wall coverings for homes, offices, and commercial spaces.
Card Holder
Durable, waterproof, and customizable ideal for branding, labeling, and outdoor use.
Car wraps
Vinyl covers for cars used for branding or custom designs.
Backlit film
Translucent film for vibrant, illuminated displays used in lightboxes and signage.
Flex banners
Durable and weather-resistant material used for outdoor and indoor advertising displays.
